1. Focus on analyzing the pitfalls

Look for hook points from a system perspective, rather than capturing packets for the sake of capturing them.

1.okhttp calling process

public static final MediaType JSON
= MediaType.get("application/json; charset=utf-8");

OkHttpClient client = new OkHttpClient();

String post(String url, String json) throws IOException {
RequestBody body = RequestBody.create(json, JSON);
Request request = new Request.Builder()
.url(url)
.post(body)
.build();
try (Response response = client.newCall(request).execute()) {
return response.body().string();
}
}

Copy after login

The important code of the client is on client.newCall(). The above is an example from the okhttp official website. Starting from the interface call here, it will eventually be called to the okhttp framework. okhttp is originally an SDK. Later, AOSP has been integrated into the system, so it can be classified into the framework layer.

The framework layer is not detailed, mainly these java classes:

com.android.okhttp.internal.huc.HttpURLConnectionImpl
com.android.okhttp.internal.http.HttpEngine
com.android.okhttp.internal.http.RetryableSink
com.android.okhttp.internal.http.CacheStrategy$Factory

Copy after login

In fact, client.newCall will eventually obtain a connection through the URL

HttpURLConnection urlConnection = (HttpURLConnection) url.openConnection();

Copy after login

The urlConnection here is actually An instance of HttpURLConnectionImpl. This class has the getInputStream getOutputStream method, which internally calls HttpEngine's getBufferedRequestBody and getResponse respectively. At first, I tried hooking these two interfaces. For example, after hooking getResponse, the response can be printed out.

Later I found that Request can only output the header, not the body. So I immersed myself in the analysis and found that the function getBufferedRequestBody can be used to get a sink. Finally, RetryableSink is used as the breakthrough point. For example, hooking its write function can print out the body. The write function corresponds to urlConnection.getOutputStream().write at the app level.

Later I discovered that for a Request, the getBufferedReuqestBody function might be called more than once, so there would be a problem of data duplication. Later, I found the CacheStrategy$Factory.get point to hook, and found that there was still data duplication. It was found that all the above hooks have disadvantages

Data duplication
non-okhttp calls cannot be captured

Then the call stack starting from send, sendmsg, write, recv, and read of the native layer is also printed. Finally, after struggling for three days, I decided to give up treatment and use tools instead.

okhttp流程：sdk接口->okhttp框架->native(libc)

Copy after login

2. The pitfalls frida stepped on during the analysis process (the key points are in the comments)

android.util.Log does not print

var Logd = function Logd(tag, msg) {
Java.use("android.util.Log").d(tag, msg);
};


Logd('http-body-', '11111111111111');//该log不打印
Logd('http-body', '11111111111111');//该log打印

Copy after login

Anonymous inner classes require reflection to obtain members

var printRequest = function(request) {
var Buffer = Java.use("com.android.okhttp.okio.Buffer");
var bodyField = request.getClass().getDeclaredField('body');
bodyField.setAccessible(true);

if (request == null) return;
Logd('http', 'printRequest: request' + request);
//var requestBody = request.body();//gadget直接报错
var requestBody = bodyField.get(request);

var requestBodyClass = requestBody.getClass();
var ClassInstanceArray = Java.array('java.lang.Class', []);

//var contentLengthMethod = requestBodyClass.getMethod("contentLength");//gadget直接报错
var contentLengthMethod = requestBodyClass.getMethod("contentLength", ClassInstanceArray);

contentLengthMethod.setAccessible(true);
var ObjectInstanceArray = Java.array('java.lang.Object', []);
var contentLength = requestBody ? contentLengthMethod.invoke(requestBody, ObjectInstanceArray) : 0;
//if (contentLength == 0) contentLength = contentLen;
Logd('http', 'printRequest contentLength: ' + contentLength);
if (contentLength > 0) {
var BufferObj = Buffer.$new();
requestBody.writeTo(BufferObj);
Logd(TAG, "\nrequest body :\n" + BufferObj.readString() + "\n");
}
};

Copy after login

android.os.Bundle printing requires Bundle unparcel

var printIntentAndExtras = function printIntentAndExtras(intentObj) {
if (intentObj == null) return;
var Intent = Java.use("android.content.Intent");
var Bundle = Java.use("android.os.Bundle");
var bundleObj = Intent.getExtras.call(intentObj);

if (bundleObj != null) {
Bundle.getSize.call(bundleObj, null);//调用getSize即可反序列化
}

Logd(TAG, ‘printIntentAndExtras ’ + bundleObj);
};

Copy after login

In fact, the pitfalls mentioned above are not the only pitfalls I have encountered. At the beginning, I also tried some frida network interception solutions. I also carefully studied the Interceptor solution of okhttp. Finally, I found that the app also used an interceptor, so a conflict occurred and the solution could not be used. .

I also purely analyzed the smali of the app, looking for the call stack and network requests. In the end, there were only a few relatively small gains, which may not be useful to readers, but I recorded them so that I can recall them later.

java.net.URL interception

var URLHook = function() {
var URL = Java.use('java.net.URL');
URL.openConnection.overload().implementation = function() {
var retval = this.openConnection();
Logd('URL', openConnection' + retval);
return retval;
};
};//URL.openConnection调用概率比较大，但是不一定对网络进行请求

Copy after login

Interception where app uses json before calling http request, this is just one of them

var jsonHook = function() {
var xx = Java.use('e.h.a.a');//app smali
var xxa_method = xx.a.overload('org.json.JSONObject', 'java.lang.String', 'java.lang.String');
xxa_method.implementation = function(jsonObj, str1, str2) {
Logd("json", jsonObj + " str1: " + str1 + " str2" + str2);
xxa_method.call(this, jsonObj, str1, str2);
}
}

Copy after login

trace http related class

var traceAllHttpClass = function() {
Java.perform(function() {
Java.enumerateLoadedClasses({
onMatch: function(name, handle) {
/*"e.h.a.a$a",起初也拦截过app的该混淆类*/
if (name.indexOf("com.android.okhttp.Http") != -1 || name.indexOf("com.android.okhttp.Request") != -1
|| name.indexOf("com.android.okhttp.internal") != -1) {
traceClass(name);//对这三个class进行trace
}
},
onComplete: function() {
}
});
});
};

Copy after login

Request$Builder interception

var BuilderClass = Java.use('com.android.okhttp.Request$Builder')

BuilderClass.build.implementation = function () {
//LOG('com.android.okhttp.HttpUrl$Builder.build overload', { c: Color.Light.Cyan });
//printBacktrace();
var retval = this.build();
Logd(TAG, "retval:" + retval);
printRequest(retval);
return retval;
}

Copy after login

property_get interception

var nativePropertyGetAddr = Module.findExportByName(null, '__system_property_get');
Interceptor.attach(nativePropertyGetAddr, {
onEnter: function onEnter(args) {
this._name = args[0].readCString();
this._value = args[1];
},
onLeave: function onLeave(retval) {
if (this._name.indexOf("ro.build.id") != -1) {
var virtualDevice = getVirtualDevice();
if (DEBUG_PROP) Logd(TAG, "__system_property_get fake " + this._name + "=>to " + virtualDevice.build_id);

this._value.writeUtf8String(virtualDevice.build_id);
}

var strFilter = /^ro\./g;
if (DEBUG_PROP && this._name.match(strFilter) != null) Logd(TAG, "__system_property_get " + this._name);
}
});

Copy after login

2. Dealing with user expiration caused by device android_id

var DEBUG_PROP = false;
var DEVICE_CONFIG = "/sdcard/.device";

function getVirtualDevice() {
var nativeOpen = new NativeFunction(Module.findExportByName(‘libc.so’, 'open'), 'int', ['pointer', 'int']);
var nativeRead = new NativeFunction(Module.findExportByName('libc.so', 'read'), 'int', ['int', 'pointer', 'int']);
var fd = nativeOpen(Memory.allocUtf8String(DEVICE_CONFIG), 0);
var mem = Memory.alloc(1024);
var readLen = nativeRead(fd, mem, 1024);
var json = JSON.parse(mem.readCString(readLen));
return json;
}

Secure.getString.implementation = function () {
var retval = this.getString(arguments[0], arguments[1]);
if (DEBUG_PROP) Logd(TAG, "Settings.Secure get " + arguments[1] + " val " + retval);

if (arguments[1].indexOf("android_id") != -1) {
var virtualDevice = getVirtualDevice();
return virtualDevice.android_id;
}

return retval;
};

Copy after login

3. Use the packet capture tool fiddle to capture packets and get out of the trap

1.fiddle proxy settings are OK, app But unable to log in

After analyzing the adb log, the process has java.security.cert.CertPathValidatorException printed. I have also seen some posts about frida intercepting packets and bypassing certificates before. Try a brute force search first:

Java.perform(function(){
const groups = Java.enumerateMethods('*!verify/u');
var classes = null;
for(var i in groups){
var classes = groups[i]['classes'];

for(var i in classes){
Java.use(classes[i]['name'])
.verify
.overload('java.lang.String', 'javax.net.ssl.SSLSession')
.implementation = function() {
printBacktrace();
LOG("[+] invoke verify", { c: Color.Red });
return true;
}
}
}
});

Copy after login

Even if you directly force verify to return true, you still cannot log in because the same SSL problem error occurs. I found the answer after searching on Baidu. Unpack apktool, then modify

res/xml/network_security_config.xml
<?xml version="1.0" encoding="utf-8"?>
<network-security-config>
<base-config cleartextTrafficPermitted="true">
<trust-anchors>
<certificates src="system" />
<!--添加fiddle证书可信任
<certificates src="user" />
-->
</trust-anchors>
</base-config>
</network-security-config>

Copy after login

to repackage the signature and run it. Fiddle caught the package and the app can log in normally. I was lucky this time. The SSL verification of the app only has one-way app verification. Verification, the server did not perform verification.

4. End

I have been tossing and turning from Tuesday afternoon to Friday. Finally, it is not a good method to find hook points from HttpEngine at the system level, and the disadvantages are already clear. Therefore, on Sunday, I used packet capture tools and various methods found on Baidu to gradually solve the problems encountered.

The following are the two packages caught:

HTTP/1.1 200 OK
Date: Sun, 16 Aug 2020 06:27:34 GMT
Content-Type: application/json
Content-Length: 101
Connection: keep-alive
Grpc-Metadata-Content-Type: application/grpc
Vary: Origin
Vary: Accept-Encoding

{"result":{"errno":"OK","errmsg":"成功"},"data":{"version":"xxxxxxxx-351e-40cf-aaa9-3177d6df9b7f"}}
-----------------------------------
HTTP/1.1 200 OK
Date: Sun, 16 Aug 2020 06:27:34 GMT
Content-Type: application/json
Content-Length: 99
Connection: keep-alive
Grpc-Metadata-Content-Type: application/grpc
Vary: Origin
Vary: Accept-Encoding

{"result":{"errno":"OK","errmsg":"成功"},"data":{"nodeToken":"xxxxxxxc24d79f55c0b07beaf50cb566"}}

Copy after login

POST https://tap-xxxxxxx.xxxxxx.com/api/v2/Android/analytics/basic HTTP/1.1
Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cjbcjdsabcjvbXVCJ9.eyJ1aWQiOjE4ODMzMDEsInNlY3JldCI6IjAzNzE0M2Y3LTExMTUtNGY2Yi1iNzQxLWUyMjc5ZDM3MGY3MCIsImV4cCI6MTU5NzgxNjQ0MiwiaXNzIjoiZ3Vlc3QgbG9naW4ifQ.W3SiO0-afbhxPITjRinnhyWhZLy1bzZhYexm5VCWklI
X-Device-ID: 9xxxxxxx84d4542e
X-Loc: ["China","Shanghai","Shanghai","","ChinaUnicom","31.224349","121.4767528","Asia/Shanghai","UTC+8","310000","86","CN","AP","xxx.166.xxx.xxx"]
X-App-Version: 2.2.0
Content-Type: application/json; charset=utf-8
Content-Length: 208
Host: xx-xxxx.xxxxxx.com
Connection: Keep-Alive
Accept-Encoding: gzip
User-Agent: okhttp/4.7.2

{"deviceID":"9xxxxxxx84d4542e","model":"V1813BA","systemVersion":"9","version":"2.2.0","location":{"latitude":xx.x99x990990991,"longitude":xxx.26689769073256},"network":{"g2":0,"g3":0,"g4":4,"g5":0,"wifi":4}}

-----------------------------------
HTTP/1.1 200 OK
Date: Sun, 16 Aug 2020 06:27:35 GMT
Content-Type: application/json
Content-Length: 43
Connection: keep-alive
Grpc-Metadata-Content-Type: application/grpc
Vary: Origin
Vary: Accept-Encoding

{"result":{"errno":"OK","errmsg":"成功"}}

Copy after login
