Analyze the principle of Vue2 implementing composition API

Since the release of Vue3, the word composition API has come into the vision of students who write Vue, I believe Everyone has always heard that the composition API is much better than the previous options API. Now due to the release of the @vue/composition-api plug-in, Vue2 students can also get on board. Next, we will mainly use the responsive ref and reactive to conduct an in-depth analysis of how this plug-in implements this function.

How to use

// 入口文件引入并注册
import Vue from 'vue'
import VueCompositionAPI from '@vue/composition-api'

Vue.use(VueCompositionAPI)

// vue文件使用
import { defineComponent, ref, reactive } from '@vue/composition-api'

export default defineComponent({
  setup () {
     const foo = ref('foo');
     const obj = reactive({ bar: 'bar' });

     return {
        foo,
        obj
     }
  }
})

How about it? After reading it, do you feel exactly the same as vue3? You may think:

• This is vue2 Ah, my previous data and methods also have variables and methods in them, how can I do it the same as setup The return values ​​are merged together. [Related recommendations: vuejs video tutorial, web front-end development]

• vue2 is not only defined in Will the data in data be processed responsively? How do ref and reactive do it?

• vue2 Constraints defined by responsive data (add attributes that are not assigned to the original object, modify array subscripts, etc.), use ref instead Is it okay with reactive?

Of course there are still a lot of doubts, because the plug-in provides quite a lot of API, covering most of what Vue3 has, here Let’s analyze how it is done mainly from these questions.

Principle Analysis

Thanks to Vue’s plug-in system, @vue/composition-api is like vue-router and vuex are also injected through officially provided plug-ins.

// 这里只贴跟本章要讲的相关代码

funciton mixin (Vue) {
    Vue.mixin({
      beforeCreate: functionApiInit
   }
}

function install (Vue) {
    mixin(Vue);
}

export const Plugin = {
  install: (Vue: VueConstructor) => install(Vue),
}

Vue The plug-in exposes a install method to the outside. When use is called, this method will be called and Vue The constructor is passed in as a parameter, and then Vue.mixin is called to handle the function when mixing in the corresponding hook.

The next step is to look at what functionApiInit does

function functionApiInit(this: ComponentInstance) {
  const vm = this
  const $options = vm.$options
  const { setup, render } = $options

  // render 相关


  const { data } = $options

  $options.data = function wrappedData() {
    initSetup(vm, vm.$props)
    return isFunction(data)
     ? (
        data as (this: ComponentInstance, x: ComponentInstance) => object
      ).call(vm, vm)
     : data || {}
  }

because Vue is in beforeCreated and created During the life cycle, the data will be processed by initState. When processing data, $options.data will be called to obtain the defined data. , so the function is re-wrapped here. This is one of the reasons why beforeCreate hook injection is chosen. It must be wrapped before the function is called. Next, let’s see what initSetup does

function initSetup(vm: ComponentInstance, props: Record<any, any> = {}) {
  const setup = vm.$options.setup!
  const ctx = createSetupContext(vm)
  const instance = toVue3ComponentInstance(vm)
  instance.setupContext = ctx

  def(props, &#39;__ob__&#39;, createObserver())
  resolveScopedSlots(vm, ctx.slots)

  let binding: ReturnType<SetupFunction<Data, Data>> | undefined | null
  activateCurrentInstance(instance, () => {
    binding = setup(props, ctx)
  })

   // setup返回是函数的情况 需要重写render函数

  const bindingObj = binding

  Object.keys(bindingObj).forEach((name) => {
    let bindingValue: any = bindingObj[name]

    // 数据处理

    asVmProperty(vm, name, bindingValue)
  })
  return
  }
}

This function is relatively long, and the code logic that is not on the main line to be explained this time has been deleted. This function mainly creates ctx and convert the vm instance into the instance defined by the Vue3 data type, then execute the setup function to get the return value, and then traverse For each property, call asVmProperty to mount it on vm. Of course, the mounting here is not by directly adding the properties and values ​​to vm. Doing so will There is a problem, that is, subsequent modifications to this attribute cannot be synchronized to vm. The most common data proxy of Vue is used here.

export function asVmProperty(
  vm: ComponentInstance,
  propName: string,
  propValue: Ref<unknown>
) {
  const props = vm.$options.props
  if (!(propName in vm) && !(props && hasOwn(props, propName))) {
    if (isRef(propValue)) {
      proxy(vm, propName, {
        get: () => propValue.value,
        set: (val: unknown) => {
          propValue.value = val
        },
      })
    } else {
      proxy(vm, propName, {
        get: () => {
          if (isReactive(propValue)) {
            ;(propValue as any).__ob__.dep.depend()
          }
          return propValue
        },
        set: (val: any) => {
          propValue = val
        },
      })
    }
}

Seeing this, I believe you have understood why the returned value defined in setup can be used in template, data, methods etc., because the returned things have been proxied to vm.

Responsiveness (ref reactive implementation)

Next let’s talk about responsiveness and why ref and reactive can also make data reactive. The implementation of

ref is actually a re-encapsulation of reactive, mainly used for basic types.

function ref(raw?: unknown) {
  if (isRef(raw)) {
    return raw
  }

  const value = reactive({ [RefKey]: raw })
  return createRef({
    get: () => value[RefKey] as any,
    set: (v) => ((value[RefKey] as any) = v),
  })
}

Because reactive must accept an object, so a constant is used here as the key of ref, which is

const value = reactive({
  "composition-api.refKey": row
})

export function createRef<T>(
  options: RefOption<T>,
  isReadonly = false,
  isComputed = false
): RefImpl<T> {
  const r = new RefImpl<T>(options)

  const sealed = Object.seal(r)
  if (isReadonly) readonlySet.set(sealed, true)
  return sealed
}

export class RefImpl<T> implements Ref<T> {
  readonly [_refBrand]!: true
  public value!: T
  constructor({ get, set }: RefOption<T>) {
    proxy(this, &#39;value&#39;, {
      get,
      set,
    })
  }
}

通过 new RefImpl 实例，该实例上有一个 value 的属性，对 value 做代理，当取值的时候返回 value[RefKey]，赋值的时候赋值给 value[RefKey], 这就是为什么 ref 可以用在基本类型，然后对返回值的 .value 进行操作。调用 object.seal 是把对象密封起来（会让这个对象变的不能添加新属性，且所有已有属性会变的不可配置。属性不可配置的效果就是属性变的不可删除，以及一个数据属性不能被重新定义成为访问器属性，或者反之。但属性的值仍然可以修改。）

我们主要看下 reactive 的实现

export function reactive<T extends object>(obj: T): UnwrapRef<T> {
    const observed = observe(obj)
    setupAccessControl(observed)
    return observed as UnwrapRef<T>
}


export function observe<T>(obj: T): T {
  const Vue = getRegisteredVueOrDefault()
  let observed: T
  if (Vue.observable) {
    observed = Vue.observable(obj)
  } else {
    const vm = defineComponentInstance(Vue, {
      data: {
        $$state: obj,
      },
    })
    observed = vm._data.$$state
  }

  return observed
}

我们通过 ref 或者 reactive 定义的数据，最终还是通过了变成了一个 observed 实例对象，也就是 Vue2 在对 data 进行处理时，会调用 observe 返回的一样，这里在 Vue2.6+ 把observe 函数向外暴露为 Vue.observable，如果是低版本的话，可以通过重新 new 一个 vue 实例，借助 data 也可以返回一个 observed 实例，如上述代码。

因为在 reactive 中定义的数据，就如你在 data 中定义的数据一样，都是在操作返回的 observed ，当你取值的时候，会触发 getter 进行依赖收集，赋值时会调用 setter 去派发更新， 只是定义在 setup 中，结合之前讲到的 setup 部分，比如当我们在 template 中访问一个变量的值时，vm.foo -> proxy 到 setup 里面的 foo -> observed 的 foo ，完成取值的流程，这会比直接在 data 上多代理了一层，因此整个过程也会有额外的性能开销。

因此使用该 API 也不会让你可以直接规避掉 vue2 响应式数据定义的约束，因为最终还是用 Object.defineProperty 去做对象拦截，插件同样也提供了 set API 让你去操作对象新增属性等操作。

总结

通过上面的了解，相信你一定对于 Vue2 如何使用 composition API 有了一定的了解，因为 API 相当多， 响应式相关的就还有 toRefs、toRef、unref、shallowRef、triggerRef 等等，这里就不一一分析，有兴趣的可以继续看源码的实现。

写 Vue2 的同学也可以不用羡慕写 Vue3 的同学了，直接引入到项目就可以使用起来，虽然没有 vue3 那么好的体验，但是绝大部分场景还是相同的，使用时注意 README 文档最后的限制章节，里面讲了一些使用限制。

（学习视频分享：vuejs入门教程、编程基础视频）
