Understanding MongoDB Storage Engines: WiredTiger Deep Dive

WiredTiger is MongoDB’s default storage engine since version 3.2, providing high performance, scalability, and modern features. 1. It uses document-level locking and MVCC for high concurrency, allowing reads and writes to proceed without blocking each other. 2. Data is stored using B-trees, with in-memory modifications flushed to disk during periodic checkpoints (every 60 seconds by default), enabling fast crash recovery by replaying only post-checkpoint logs. 3. MVCC ensures consistent snapshots, so long-running queries aren’t blocked by writes and vice versa. 4. Built-in compression (Snappy, Zlib, Zstd) reduces storage and I/O for both collections and indexes, improving cache efficiency. 5. WiredTiger manages its own cache (default: 50% of RAM minus 1GB), which stores data, indexes, and metadata—proper sizing is critical to avoid excessive disk I/O. 6. The Write-Ahead Log (WAL) guarantees durability by logging writes before applying them, with fsync intervals every 100ms; j: true ensures journal sync for safety, while j: false trades durability for speed. 7. Alternatives may be considered for low-memory systems (

MongoDB’s performance and scalability heavily depend on its storage engine, and WiredTiger is the default since MongoDB 3.2. If you're using a modern version of MongoDB, chances are you're already using WiredTiger—so understanding how it works under the hood can help you optimize performance, manage resources, and troubleshoot issues.

Let’s break down what makes WiredTiger powerful and how it handles data behind the scenes.

What Is WiredTiegel and Why It Matters

WiredTiger is a high-performance, scalable storage engine designed for workloads with high concurrency and large datasets. Unlike the older MMAPv1 engine, WiredTiger brings modern database features like document-level concurrency control, compression, and crash-safe writes.

Key advantages:

• Document-level locking (vs. collection-level in MMAPv1) → higher concurrency
• Snapshots and MVCC (Multi-Version Concurrency Control) → consistent reads without blocking writes
• Configurable compression → reduced storage footprint
• Write-ahead logging (WAL) → durability and crash recovery

It's built to scale efficiently on modern hardware, especially systems with multiple cores and SSDs.

How WiredTiger Stores Data: B-Trees and Checkpoints

At its core, WiredTiger uses a B-tree (balanced tree) structure to organize data on disk and in memory.

In-Memory vs. On-Disk Structure

• When you insert or update a document, it first goes into the in-memory B-tree.
• Changes are tracked in the WiredTiger log (WAL) for durability.
• Periodically, WiredTiger creates a checkpoint—a consistent snapshot of the data written to disk.

This means:

• Reads can access either the in-memory tree (fast) or the last checkpoint (on disk).
• Writes are non-blocking thanks to MVCC and checkpoints.

Checkpointing Explained

Checkpoints are crucial for recovery and performance:

• They occur every 60 seconds by default (configurable).
• During a checkpoint, dirty pages (modified in memory) are flushed to disk in a consistent state.
• After a crash, MongoDB replays only the log entries after the last checkpoint.

This reduces recovery time significantly compared to replaying the entire oplog or journal.

Concurrency and Isolation: MVCC in Action

WiredTiger uses MVCC (Multi-Version Concurrency Control) to allow concurrent reads and writes without locks blocking each other.

Here’s how it works:

• Each operation runs in a snapshot of the database at a point in time.
• Readers see a consistent view, even if writes are happening.
• Writers don’t block readers, and vice versa (as long as they’re not modifying the same document).

For example:

• A long-running analytics query won’t be blocked by incoming inserts.
• Two updates to different documents can proceed in parallel.

This is a big win for applications requiring high throughput and low latency.

Storage Efficiency: Compression and Indexing

One of WiredTiger’s standout features is built-in compression, which saves disk space and reduces I/O.

Data Compression Options

WiredTiger supports:

• Snappy (default): Fast, moderate compression
• Zlib: Higher compression, slower
• Zstd (from MongoDB 4.2 ): Balanced speed and ratio

Compression is applied to:

• Collections (data)
• Indexes

You can configure compression per collection:

db.createCollection("logs", {
  storageEngine: {
    wiredTiger: {
      configString: "block_compressor=zstd"
    }
  }
})

Index Behavior

• All indexes use the same storage engine.
• Index keys are also compressed.
• Secondary indexes are updated incrementally and benefit from the same concurrency model.

? Tip: Compressed indexes reduce memory pressure in the WiredTiger cache, allowing more hot data to stay in RAM.

WiredTiger Cache: Managing Memory Usage

WiredTiger manages its own in-memory cache, separate from the filesystem cache.

By default:

• The cache size is 50% of RAM minus 1 GB, capped at 1 TB.
• It holds:
  • Most recently used data (working set)
  • Indexes
  • Internal metadata

You can adjust it in mongod.conf:

storage:
  wiredTiger:
    engineConfig:
      configString: "cache_size=4G"

⚠️ Warning: Don’t set it too high. Leave room for the OS filesystem cache and other processes.

If your working set exceeds the cache size, you’ll see more disk I/O and slower queries.

Logging and Durability: Write-Ahead Log (WAL)

WiredTiger uses a Write-Ahead Log (WAL) to ensure durability:

• Every write is first written to the log.
• Logs are fsynced every 100ms by default (commit_timestamp_frequency).
• This guarantees that even if MongoDB crashes, no committed data is lost.

The log is stored in dbPath under journal/.

While checkpoints write data to disk periodically, the WAL ensures granular durability between checkpoints.

You can tune durability vs. performance:

• Set j: true on writes for guaranteed journal sync.
• Or use j: false for higher throughput (but risk of minor data loss on crash).

When to Consider Alternatives?

While WiredTiger is excellent for most use cases, it’s not always the best fit.

Avoid or reconsider if:

• You're on very low-memory systems (
• You need encrypted at rest with older MongoDB versions: Only Enterprise offers native encryption (though filesystem-level encryption works).
• You’re migrating from MMAPv1 and have specific performance expectations (benchmark first).

There’s also in-memory storage engine (Enterprise only), which keeps all data in RAM for ultra-low latency—useful for caching or real-time analytics.

Final Thoughts

WiredTiger is a robust, modern storage engine that powers most MongoDB deployments today. Its combination of concurrency, compression, and crash safety makes it ideal for everything from small apps to large-scale distributed systems.

To get the most out of it:

• Monitor cache usage (db.serverStatus().wiredTiger.cache)
• Tune compression based on your I/O vs. CPU trade-off
• Understand checkpoint and journal behavior for disaster recovery
• Size your RAM appropriately for cache and system needs

It’s not magic—but with the right understanding, it’s a powerful tool in your MongoDB toolkit.

Basically, if you're using MongoDB post-3.2, you're likely already benefiting from WiredTiger. Now you know how.
