Setting up asynchronous primary-replica replication in MySQL

Jul 06, 2025 am 02:52 AM
mysql master-slave replication

To set up asynchronous master-slave replication for MySQL, follow these steps: 1. Prepare the master server, enable binary logs and set a unique server-id, create a replication user and record the current log location; 2. Use mysqldump to back up the master library data and import it to the slave server; 3. Configure the server-id and relay-log of the slave server, use the CHANGE MASTER command to connect to the master library and start the replication thread; 4. Check for common problems, such as network, permissions, data consistency and self-increase conflicts, and monitor replication delays. Follow the steps above to ensure that the configuration is completed correctly.

Setting up asynchronous primary-replica replication in MySQL

Setting up asynchronous primary-replica replication in MySQL is a common way to offload read traffic, provide redundancy, and help with backups. It's not overly complicated, but there are several important steps you need to follow carefully.

Setting up asynchronous primary-replica replication in MySQL

1. Prepare the Primary Server

Before setting up replication, make sure your primary server is configured correctly. You'll need to enable binary logging and assign a unique server ID.

Setting up asynchronous primary-replica replication in MySQL
  • Edit your MySQL configuration file (usually my.cnf or my.ini ) and add these lines under the [mysqld] section:
 server-id=1
log-bin=mysql-bin
  • Restart MySQL to apply the changes.
  • Create a dedicated replication user on the primary:
 CREATE USER 'replica_user'@'%' IDENTIFIED BY 'your_password';
GRANT REPLICATION SLAVE ON *.* TO 'replica_user'@'%';
FLUSH PRIVILEGES;

This user will be used by the replica to connect and read binary logs from the primary.

Now check the current binary log position on the primary:

Setting up asynchronous primary-replica replication in MySQL
 SHOW MASTER STATUS;

Take note of the File and Position values ​​— you'll need them later when configuring the replica.


2. Take a Backup of the Primary Data

To get the replica in sync, you need a consistent snapshot of the primary data. The easiest way is to use mysqldump .

Run this command on the primary:

 mysqldump --all-databases --master-data=2 --single-transaction -u root -p > backup.sql
  • --master-data=2 adds the binary log position as a comment in the dump file.
  • --single-transaction ensures a consistent view of the database without locking tables for long.

Transfer the backup file to the replica server using scp , rsync , or any method you prefer.

Then import it into the replica:

 mysql -u root -p < backup.sql

3. Configure the Replica Server

On the replica, edit its MySQL config and set a different server ID (it must be unique across the replication topology):

 server-id=2

Also, if you want the replica to keep a record of the replicated events, you can enable relay logs:

 relay-log=mysql-relay-bin

Restart MySQL after making changes.

Now, configure the replica to connect to the primary using the credentials and log position you recorded earlier:

 CHANGE MASTER TO
  MASTER_HOST=&#39;primary_server_ip&#39;,
  MASTER_USER=&#39;replica_user&#39;,
  MASTER_PASSWORD=&#39;your_password&#39;,
  MASTER_LOG_FILE=&#39;recorded_log_file_name&#39;,
  MASTER_LOG_POS=recorded_position;

Once that's done, start the replication threads:

 START SLAVE;

You can check the status with:

 SHOW SLAVE STATUS\G

Look for Slave_IO_Running: Yes and Slave_SQL_Running: Yes . If both are yes and there are no errors, replication is working.


4. Common Issues and Tips

Replication settings can fail for various reasons. Here are some common issues and how to avoid them:

  • Network connectivity : Make sure the replica can reach the primary on port 3306.
  • Firewall rules : Double-check that the firewall allows traffic between the servers.
  • User permissions : Confirm that the replication user has the correct privileges.
  • Data inconsistency : If the replica's data doesn't match the primary, replication might break. Use tools like pt-table-checksum to verify consistency.
  • Auto-increment conflicts : If you ever switch to multi-source or circular replication, consider adjusting auto_increment_offset and auto_increment_increment .

Also, don't forget to monitor replication lag. You can see it via SHOW SLAVE STATUS — look at the Seconds_Behind_Master field.


That's basically how you set up asynchronous replication in MySQL. It's straightforward once you've done it a few times, but always double-check each step — especially the server IDs and log positions.
