并行处理视频流：使用 PySpark 进行大规模视频分析

from pyspark import SQLContext, SparkConf, SparkContext
from pyspark.sql import SparkSession
import pyspark.sql.functions as F

# 配置 Spark
conf = SparkConf().setAppName("myApp").setMaster("local[40]")
spark = SparkSession.builder.master("local[40]").config("spark.driver.memory", "30g").getOrCreate()

sc = spark.sparkContext
sqlContext = SQLContext(sc)

import cv2
import os
import uuid
import ffmpeg
import subprocess
import numpy as np

from scipy.optimize import linear_sum_assignment
import pyspark.sql.functions as F
from pyspark.sql import Row
from pyspark.sql.types import (StructType, StructField,
                               IntegerType, FloatType,
                               ArrayType, BinaryType,
                               MapType, DoubleType, StringType)

from pyspark.sql.window import Window
from pyspark.ml.feature import StringIndexer
from pyspark.sql import Row, DataFrame, SparkSession

import pathlib

# 指定视频文件目录
input_dir = "../data/video_files/faces/"
pathlist = list(pathlib.Path(input_dir).glob('*.mp4'))
pathlist = [Row(str(ele)) for ele in pathlist]

# 创建 DataFrame
column_name = ["video_uri"]
df = sqlContext.createDataFrame(data=pathlist, schema=column_name)

print("Initial dataframe")
df.show(10, truncate=False)

# 定义视频元数据 Schema
video_metadata = StructType([
    StructField("width", IntegerType(), False),
    StructField("height", IntegerType(), False),
    StructField("num_frames", IntegerType(), False),
    StructField("duration", FloatType(), False)
])

# 定义 Shot Schema
shots_schema = ArrayType(
    StructType([
        StructField("start", FloatType(), False),
        StructField("end", FloatType(), False)
    ]))

# 定义 UDF：提取视频元数据
@F.udf(returnType=video_metadata)
def video_probe(uri):
    probe = ffmpeg.probe(uri, threads=1)
    video_stream = next(
        (
            stream
            for stream in probe["streams"]
            if stream["codec_type"] == "video"
        ),
        None,
    )
    width = int(video_stream["width"])
    height = int(video_stream["height"])
    num_frames = int(video_stream["nb_frames"])
    duration = float(video_stream["duration"])
    return (width, height, num_frames, duration)

# 定义 UDF：提取视频帧
@F.udf(returnType=ArrayType(BinaryType()))
def video2images(uri, width, height,
                 sample_rate: int = 5,
                 start: float = 0.0,
                 end: float = -1.0,
                 n_channels: int = 3):
    """
    Uses FFmpeg filters to extract image byte arrays
    and sampled & localized to a segment of video in time.
    """
    video_data, _ = (
        ffmpeg.input(uri, threads=1)
        .output(
            "pipe:",
            format="rawvideo",
            pix_fmt="rgb24",
            ss=start,
            t=end - start,
            r=1 / sample_rate,
        ).run(capture_stdout=True))
    img_size = height * width * n_channels
    return [video_data[idx:idx + img_size] for idx in range(0, len(video_data), img_size)]

# 添加视频元数据列
df = df.withColumn("metadata", video_probe(F.col("video_uri")))
print("With Metadata")
df.show(10, truncate=False)

# 提取视频帧
df = df.withColumn("frame", F.explode(
    video2images(F.col("video_uri"), F.col("metadata.width"), F.col("metadata.height"), F.lit(1), F.lit(0.0),
                 F.lit(5.0))))

# 定义人脸检测相关 Schema 和 UDF
box_struct = StructType(
    [
        StructField("xmin", IntegerType(), False),
        StructField("ymin", IntegerType(), False),
        StructField("xmax", IntegerType(), False),
        StructField("ymax", IntegerType(), False)
    ]
)

def bbox_helper(bbox):
    top, right, bottom, left = bbox
    bbox = [top, left, bottom, right]

    return list(map(lambda x: max(x, 0), bbox))

@F.udf(returnType=ArrayType(box_struct))
def face_detector(img_data, width=1920, height=1080, n_channels=3):
    img = np.frombuffer(img_data, np.uint8).reshape(height, width, n_channels)
    faces = face_recognition.face_locations(img)
    return [bbox_helper(f) for f in faces]

# 进行人脸检测
df = df.withColumn("faces", face_detector(F.col("frame"), F.col("metadata.width"), F.col("metadata.height")))

# 定义人脸追踪相关 Schema 和 UDF
annot_schema = ArrayType(
    StructType(
        [
            StructField("bbox", box_struct, False),
            StructField("tracker_id", StringType(), False),
        ]
    )
)

def bbox_iou(b1, b2):
    L = list(zip(b1, b2))
    left, top = np.max(L, axis=1)[:2]
    right, bottom = np.min(L, axis=1)[2:]
    if right < left or bottom < top:
        return 0
    b_area = lambda b: (b[2] - b[0]) * (b[3] - b[1])
    inter_area = b_area([left, top, right, bottom])
    b1_area, b2_area = b_area(b1), b_area(b2)
    iou = inter_area / float(b1_area + b2_area - inter_area)
    return iou

@F.udf(returnType=MapType(IntegerType(), IntegerType()))
def tracker_match(trackers, detections, bbox_col="bbox", threshold=0.3):
    """
    Match Bounding Boxes across successive image frames.
    """
    from scipy.optimize import linear_sum_assignment

    similarity = bbox_iou
    if not trackers or not detections:
        return {}
    if len(trackers) == len(detections) == 1:
        if (
                similarity(trackers[0][bbox_col], detections[0][bbox_col])
                >= threshold
        ):
            return {0: 0}

    sim_mat = np.array(
        [
            [
                similarity(tracked[bbox_col], detection[bbox_col])
                for tracked in trackers
            ]
            for detection in detections
        ],
        dtype=np.float32,
    )

    matched_idx = linear_sum_assignment(-sim_mat)
    matches = []
    for m in matched_idx:
        try:
            if sim_mat[m[0], m[1]] >= threshold:
                matches.append(m.reshape(1, 2))
        except:
            pass

    if len(matches) == 0:
        return {}
    else:
        matches = np.concatenate(matches, axis=0, dtype=int)

    rows, cols = zip(*np.where(matches))
    idx_map = {cols[idx]: rows[idx] for idx in range(len(rows))}
    return idx_map

@F.udf(returnType=ArrayType(box_struct))
def OFMotionModel(frame, prev_frame, bboxes, height, width):
    if not prev_frame:
        prev_frame = frame
    gray = cv2.cvtColor(np.frombuffer(frame, np.uint8).reshape(height, width, 3), cv2.COLOR_BGR2GRAY)
    prev_gray = cv2.cvtColor(np.frombuffer(prev_frame, np.uint8).reshape(height, width, 3), cv2.COLOR_BGR2GRAY)

    inst = cv2.DISOpticalFlow.create(cv2.DISOPTICAL_FLOW_PRESET_MEDIUM)
    inst.setUseSpatialPropagation(False)

    flow = inst.calc(prev_gray, gray, None)

    h, w = flow.shape[:2]
    shifted_boxes = []
    for box in bboxes:
        xmin, ymin, xmax, ymax = box
        avg_y = np.mean(flow[int(ymin):int(ymax), int(xmin):int(xmax), 0])
        avg_x = np.mean(flow[int(ymin):int(ymax), int(xmin):int(xmax), 1])

        shifted_boxes.append(
            {"xmin": int(max(0, xmin + avg_x)), "ymin": int(max(0, ymin + avg_y)), "xmax": int(min(w, xmax + avg_x)),
             "ymax": int(min(h, ymax + avg_y))})
    return shifted_boxes

def match_annotations(iterator, segment_id="video_uri", id_col="tracker_id"):
    """
    Used by mapPartitions to iterate over the small chunks of our hierarchically-organized data.
    """

    matched_annots = []
    for idx, data in enumerate(iterator):
        data = data[1]
        if not idx:
            old_row = {idx: uuid.uuid4() for idx in range(len(data[1]))}
            old_row[segment_id] = data[0]
            pass
        annots = []
        curr_row = {segment_id: data[0]}
        if old_row[segment_id] != curr_row[segment_id]:
            old_row = {}
        if data[2] is not None:
            for ky, vl in data[2].items():
                detection = data[1][vl].asDict()
                detection[id_col] = old_row.get(ky, uuid.uuid4())
                curr_row[vl] = detection[id_col]
                annots.append(Row(**detection))
        matched_annots.append(annots)
        old_row = curr_row
    return matched_annots

def track_detections(df, segment_id="video_uri", frames="frame", detections="faces", optical_flow=True):
    id_col = "tracker_id"
    frame_window = Window().orderBy(frames)
    value_window = Window().orderBy("value")
    annot_window = Window.partitionBy(segment_id).orderBy(segment_id, frames)
    indexer = StringIndexer(inputCol=segment_id, outputCol="vidIndex")

    # adjust detections w/ optical flow
    if optical_flow:
        df = (
            df.withColumn("prev_frames", F.lag(F.col(frames)).over(annot_window))
            .withColumn(detections, OFMotionModel(F.col(frames), F.col("prev_frames"), F.col(detections), F.col("metadata.height"), F.col("metadata.width")))
        )

    df = (
        df.select(segment_id, frames, detections)
        .withColumn("bbox", F.explode(detections))
        .withColumn(id_col, F.lit(""))
        .withColumn("trackables", F.struct([F.col("bbox"), F.col(id_col)]))
        .groupBy(segment_id, frames, detections)
        .agg(F.collect_list("trackables").alias("trackables"))
        .withColumn(
            "old_trackables", F.lag(F.col("trackables")).over(annot_window)
        )
        .withColumn(
            "matched",
            tracker_match(F.col("trackables"), F.col("old_trackables")),
        )
        .withColumn("frame_index", F.row_number().over(frame_window))
    )

    df = (
        indexer.fit(df)
        .transform(df)
        .withColumn("vidIndex", F.col("vidIndex").cast(StringType()))
    )
    unique_ids = df.select("vidIndex").distinct().count()
    matched = (
        df.select("vidIndex", segment_id, "trackables", "matched")
        .rdd.map(lambda x: (x[0], x[1:]))
        .partitionBy(unique_ids, lambda x: int(x[0]))
        .mapPartitions(match_annotations)
    )
    matched_annotations = sqlContext.createDataFrame(matched, annot_schema).withColumn("value_index",
                                                                                       F.row_number().over(
                                                                                           value_window))

    return (
        df.join(matched_annotations, F.col("value_index") == F.col("frame_index"))
        .withColumnRenamed("value", "trackers_matched")
        .withColumn("tracked", F.explode(F.col("trackers_matched")))
        .select(
            segment_id,
            frames,
            detections,
            F.col("tracked.{}".format("bbox")).alias("bbox"),
            F.col("tracked.{}".format(id_col)).alias(id_col),
        )
        .withColumn(id_col, F.sha2(F.concat(F.col(segment_id), F.col(id_col)), 256))
        .withColumn("tracked_detections", F.struct([F.col("bbox"), F.col(id_col)]))
        .groupBy(segment_id, frames, detections)
        .agg(F.collect_list("tracked_detections").alias("tracked_detections"))
        .orderBy(segment_id, frames, detections)
    )

# 定义 DetectionTracker Transformer
from pyspark import keyword_only
from pyspark.ml.pipeline import Transformer
from pyspark.ml.param.shared import HasInputCol, HasOutputCol, Param

class DetectionTracker(Transformer, HasInputCol, HasOutputCol):
    """Detect and track."""

    @keyword_only
    def __init__(self, inputCol=None, outputCol=None, framesCol=None, detectionsCol=None, optical_flow=None):
        """Initialize."""
        super(DetectionTracker, self).__init__()
        self.framesCol = Param(self, "framesCol", "Column containing frames.")
        self.detectionsCol = Param(self, "detectionsCol", "Column containing detections.")
        self.optical_flow = Param(self, "optical_flow", "Use optical flow for tracker correction. Default is False")
        self._setDefault(framesCol="frame", detectionsCol="faces", optical_flow=False)
        kwargs = self._input_kwargs
        self.setParams(**kwargs)

    @keyword_only
    def setParams(self, inputCol=None, outputCol=None, framesCol=None, detectionsCol=None, optical_flow=None):
        """Get params."""
        kwargs = self._input_kwargs
        return self._set(**kwargs)

    def setFramesCol(self, value):
        """Set framesCol."""
        return self._set(framesCol=value)

    def getFramesCol(self):
        """Get framesCol."""
        return self.getOrDefault(self.framesCol)

    def setDetectionsCol(self, value):
        """Set detectionsCol."""
        return self._set(detectionsCol=value)

    def getDetectionsCol(self):
        """Get detectionsCol."""
        return self.getOrDefault(self.detectionsCol)

    def setOpticalflow(self, value):
        """Set optical_flow."""
        return self._set(optical_flow=value)

    def getOpticalflow(self):
        """Get optical_flow."""
        return self.getOrDefault(self.optical_flow)

    def _transform(self, dataframe):
        """Do transformation."""
        input_col = self.getInputCol()
        output_col = self.getOutputCol()
        frames_col = self.getFramesCol()
        detections_col = self.getDetectionsCol()
        optical_flow = self.getOpticalflow()

        id_col = "tracker_id"
        frame_window = Window().orderBy(frames_col)
        value_window = Window().orderBy("value")
        annot_window = Window.partitionBy(input_col).orderBy(input_col, frames_col)
        indexer = StringIndexer(inputCol=input_col, outputCol="vidIndex")

        # adjust detections w/ optical flow
        if optical_flow:
            dataframe = (
                dataframe.withColumn("prev_frames", F.lag(F.col(frames_col)).over(annot_window))
                .withColumn(detections_col,
                            OFMotionModel(F.col(frames_col), F.col("prev_frames"), F.col(detections_col)))
            )

        dataframe = (
            dataframe.select(input_col, frames_col, detections_col)
            .withColumn("bbox", F.explode(detections_col))
            .withColumn(id_col, F.lit(""))
            .withColumn("trackables", F.struct([F.col("bbox"), F.col(id_col)]))
            .groupBy(input_col, frames_col, detections_col)
            .agg(F.collect_list("trackables").alias("trackables"))
            .withColumn(
                "old_trackables", F.lag(F.col("trackables")).over(annot_window)
            )
            .withColumn(
                "matched",
                tracker_match(F.col("trackables"), F.col("old_trackables")),
            )
            .withColumn("frame_index", F.row_number().over(frame_window))
        )

        dataframe = (
            indexer.fit(dataframe)
            .transform(dataframe)
            .withColumn("vidIndex", F.col("vidIndex").cast(StringType()))
        )

        unique_ids = dataframe.select("vidIndex").distinct().count()
        matched = (
            dataframe.select("vidIndex", input_col, "trackables", "matched")
            .rdd.map(lambda x: (x[0], x[1:]))
            .partitionBy(unique_ids, lambda x: int(x[0]))
            .mapPartitions(match_annotations)
        )

        matched_annotations = sqlContext.createDataFrame(matched, annot_schema).withColumn("value_index",
                                                                                           F.row_number().over(
                                                                                               value_window))

        return (
            dataframe.join(matched_annotations, F.col("value_index") == F.col("frame_index"))
            .withColumnRenamed("value", "trackers_matched")
            .withColumn("tracked", F.explode(F.col("trackers_matched")))
            .select(
                input_col,
                frames_col,
                detections_col,
                F.col("tracked.{}".format("bbox")).alias("bbox"),
                F.col("tracked.{}".format(id_col)).alias(id_col),
            )
            .withColumn(id_col, F.sha2(F.concat(F.col(input_col), F.col(id_col)), 256))
            .withColumn(output_col, F.struct([F.col("bbox"), F.col(id_col)]))
            .groupBy(input_col, frames_col, detections_col)
            .agg(F.collect_list(output_col).alias(output_col))
            .orderBy(input_col, frames_col, detections_col)
        )

# 使用 DetectionTracker
detectTracker = DetectionTracker(inputCol="video_uri", outputCol="tracked_detections")
print(type(detectTracker))

detectTracker.transform(df)
final = track_detections(df)

print("Final dataframe")
final.select("tracked_detections").show(100, truncate=False)
