Steps to draw title bar in CAD

CAD drawing title bar steps:

1. Double-click the CAD software on your computer to open it, and then click Format/ Table style.

2. Then click to select New.

3. Then name the new style and click Continue.

#4. Then select General for format, and then click Text Style.

5. Then click Apply.

#6. Finally, click [Align] in the center of the data options.

#7. Then select the border color and line width.

#8. Unit height = font size/three-quarters*line vertical*2. It is calculated that the vertical height of a size 5 font is 0.66.

9. Finally, click OK.
