RGFW Under the Hood: Clipboard Copy/Paste

Introduction

Reading and writing to the clipboard using low-level APIs can be tricky. There are a bunch of steps required. This tutorial simplifies the process so you can easily read and write to the clipboard using the low-level APIs.

The tutorial is based on RGFW's source code and its usage of the low-level APIs.

Note: the cocoa code is written in Pure-C.

Overview

1) Clipboard Paste

X11 (init atoms, convert section, get data)
Win32 (open clipboard, get data, convert data, close clipboard)
Cocoa (set datatypes, get pasteboard, get data, convert data)

2) Clipboard Copy

X11 (init atoms, convert section, handle request, send data)
Win32 (setup global object, convert data, open clipboard, convert string, send data, close clipboard)
Cocoa (create datatype array, declare types, convert string, send data)

Clipboard Paste

X11

To handle the clipboard, you must create some Atoms via XInternAtom.
X Atoms are used to ask for or send specific data or properties through X11.

You'll need three atoms,

1) UTF8_STRING: Atom for a UTF-8 string.
2) CLIPBOARD: Atom for getting clipboard data.
3) XSEL_DATA: Atom to get selection data.

const Atom UTF8_STRING = XInternAtom(display, "UTF8_STRING", True);
const Atom CLIPBOARD = XInternAtom(display, "CLIPBOARD", 0);
const Atom XSEL_DATA = XInternAtom(display, "XSEL_DATA", 0);

Copy after login

Now, to get the clipboard data you have to request that the clipboard section be converted to UTF8 using XConvertSelection.

use XSync to send the request to the server.

XConvertSelection(display, CLIPBOARD, UTF8_STRING, XSEL_DATA, window, CurrentTime);
XSync(display, 0);

Copy after login

The selection will be converted and sent back to the client as a XSelectionNotify event. You can get the next event, which should be the SelectionNotify event with XNextEvent.

XEvent event;
XNextEvent(display, &event);

Copy after login

Check if the event is a SelectionNotify event and use .selection to ensure the type is a CLIPBOARD. Also make sure .property is not 0 and can be retrieved.

if (event.type == SelectionNotify && event.xselection.selection == CLIPBOARD && event.xselection.property != 0) {

Copy after login

You can get the converted data via XGetWindowProperty using the selection property.

    int format;
    unsigned long N, size;
    char* data, * s = NULL;
    Atom target;

    XGetWindowProperty(event.xselection.display, event.xselection.requestor,
        event.xselection.property, 0L, (~0L), 0, AnyPropertyType, &target,
        &format, &size, &N, (unsigned char**) &data);

Copy after login

Make sure the data is in the right format by checking target

    if (target == UTF8_STRING || target == XA_STRING) {

Copy after login

The data is stored in data, once you're done with it free it with XFree.

You can also delete the property via XDeleteProperty.

        XFree(data);
    }

    XDeleteProperty(event.xselection.display, event.xselection.requestor, event.xselection.property);
}

Copy after login

winapi

First, open the clipboard OpenClipboard.

if (OpenClipboard(NULL) == 0)
    return 0;

Copy after login

Get the clipboard data as a utf16 string via GetClipboardData

If the data is NULL, you should close the clipboard using CloseClipboard

HANDLE hData = GetClipboardData(CF_UNICODETEXT);
if (hData == NULL) {
    CloseClipboard();
    return 0;
}

Copy after login

Next, you need to convert the utf16 data back to utf8.

Start by locking memory for the utf8 data via GlobalLock.

wchar_t* wstr = (wchar_t*) GlobalLock(hData);

Copy after login

Use setlocale to ensure the data format is utf8.

Get the size of the UTF-8 version with wcstombs.

setlocale(LC_ALL, "en_US.UTF-8");

size_t textLen = wcstombs(NULL, wstr, 0);

Copy after login

If the size is valid, convert the data using wcstombs.

if (textLen) {
    char* text = (char*) malloc((textLen * sizeof(char)) + 1);

    wcstombs(text, wstr, (textLen) + 1);
    text[textLen] = '\0';

    free(text);
}

Copy after login

Make sure to free leftover global data using GlobalUnlock and close the clipboard with CloseClipboard.

GlobalUnlock(hData);
CloseClipboard();

Copy after login

cocoa

Cocoa uses NSPasteboardTypeString to ask for string data. You'll have to define this yourself if you're not using Objective-C.

NSPasteboardType const NSPasteboardTypeString = "public.utf8-plain-text";

Copy after login

Although the is a c-string and Cocoa uses NSStrings, you can convert the c-string to an NSString via stringWithUTF8String.

NSString* dataType = objc_msgSend_class_char(objc_getClass("NSString"), sel_registerName("stringWithUTF8String:"), (char*)NSPasteboardTypeString);

Copy after login

Now we'll use generalPasteboard to get the default pasteboard object.

NSPasteboard* pasteboard = objc_msgSend_id((id)objc_getClass("NSPasteboard"), sel_registerName("generalPasteboard"));

Copy after login

Then you can get the pasteboard's string data with the dataType using stringForType.

However, it will give you an NSString, which can be converted with UTF8String.

NSString* clip = ((id(*)(id, SEL, const char*))objc_msgSend)(pasteboard, sel_registerName("stringForType:"), dataType);
const char* str = ((const char* (*)(id, SEL)) objc_msgSend) (clip, sel_registerName("UTF8String"));

Copy after login

Clipboard Copy

X11

To copy to the clipboard you'll need a few more Atoms.

1) SAVE_TARGETS: To request a section to convert to (for copying).
2) TARGETS: To handle one requested target
3) MULTIPLE: When there are multiple request targets
4) ATOM_PAIR: To get the supported data types.
5) CLIPBOARD_MANAGER: To access data from the clipboard manager.

const Atom SAVE_TARGETS = XInternAtom((Display*) display, "SAVE_TARGETS", False);
const Atom TARGETS = XInternAtom((Display*) display, "TARGETS", False);
const Atom MULTIPLE = XInternAtom((Display*) display, "MULTIPLE", False);
const Atom ATOM_PAIR = XInternAtom((Display*) display, "ATOM_PAIR", False);
const Atom CLIPBOARD_MANAGER = XInternAtom((Display*) display, "CLIPBOARD_MANAGER", False);

Copy after login

We can request a clipboard section. First, set the owner of the section to be a client window via XSetSelectionOwner. Next request a converted section using XConvertSelection.

XSetSelectionOwner((Display*) display, CLIPBOARD, (Window) window, CurrentTime);

XConvertSelection((Display*) display, CLIPBOARD_MANAGER, SAVE_TARGETS, None, (Window) window, CurrentTime);

Copy after login

The rest of the code would exist in an event loop. You can create an external event loop from your main event loop if you wish or add this to your main event loop.

We'll be handling SelectionRequest in order to update the clipboard selection to the string data.

if (event.type == SelectionRequest) {
    const XSelectionRequestEvent* request = &event.xselectionrequest;

Copy after login

At the end of the SelectionNotify event, a response will be sent back to the requester. The structure should be created here and modified depending on the request data.

    XEvent reply = { SelectionNotify };
    reply.xselection.property = 0;

Copy after login

The first target we will handle is TARGETS when the requestor wants to know which targets are supported.

    if (request->target == TARGETS) {

Copy after login

I will create an array of supported targets

        const Atom targets[] = { TARGETS,
                                MULTIPLE,
                                UTF8_STRING,
                                XA_STRING };

Copy after login

This array can be passed using XChangeProperty.

I'll also change the selection property so the requestor knows what property we changed.

        XChangeProperty(display,
            request->requestor,
            request->property,
            4,
            32,
            PropModeReplace,
            (unsigned char*) targets,
            sizeof(targets) / sizeof(targets[0]));

        reply.xselection.property = request->property;
    }

Copy after login

Next, I will handle MULTIPLE targets.

    if (request->target == MULTIPLE) {

Copy after login

We'll start by getting the supported targets via XGetWindowProperty

        Atom* targets = NULL;

        Atom actualType = 0;
        int actualFormat = 0;
        unsigned long count = 0, bytesAfter = 0;

        XGetWindowProperty(display, request->requestor, request->property, 0, LONG_MAX, False, ATOM_PAIR, &actualType, &actualFormat, &count, &bytesAfter, (unsigned char **) &targets);

Copy after login

Now we'll loop through the supported targets. If the supported targets match one of our supported targets, we can pass the data with XChangeProperty.

If the target is not used, the second argument should be set to None, marking it as unused.

        unsigned long i;
        for (i = 0; i < count; i += 2) {
            if (targets[i] == UTF8_STRING || targets[i] == XA_STRING) {
                XChangeProperty((Display*) display,
                    request->requestor,
                    targets[i + 1],
                    targets[i],
                    8,
                    PropModeReplace,
                    (unsigned char*) text,
                    sizeof(text));
                XFlush(display);
            } else {
                targets[i + 1] = None;
            }
        }

Copy after login

You can pass the final array of supported targets to the requestor using XChangeProperty. This tells the requestor which targets to expect for the original list it sent.

The message will be sent out asap when XFlush is called.

You can free your copy of the target array with XFree.

        XChangeProperty((Display*) display,
            request->requestor,
            request->property,
            ATOM_PAIR,
            32,
            PropModeReplace,
            (unsigned char*) targets,
            count);

        XFlush(display);
        XFree(targets);

        reply.xselection.property = request->property;
    }

Copy after login

For the final step of the event, send the selection back to the requestor via XSendEvent.

Then flush the queue with XFlush.

    reply.xselection.display = request->display;
    reply.xselection.requestor = request->requestor;
    reply.xselection.selection = request->selection;
    reply.xselection.target = request->target;
    reply.xselection.time = request->time;

    XSendEvent((Display*) display, request->requestor, False, 0, &reply);
    XFlush(display);
}

Copy after login

winapi

First allocate global memory for your data and your utf-8 buffer with GlobalAlloc

HANDLE object = GlobalAlloc(GMEM_MOVEABLE, (1 + textLen) * sizeof(WCHAR));
WCHAR*  buffer = (WCHAR*) GlobalLock(object);

Copy after login

Next, you can use MultiByteToWideChar to convert your string to a wide string.

MultiByteToWideChar(CP_UTF8, 0, text, -1, buffer, textLen);

Copy after login

Now unlock the global object and open the clipboard

GlobalUnlock(object);
OpenClipboard(NULL);

Copy after login

To update the clipboard data, you start by clearing what's currently on the clipboard via EmptyClipboard you can use SetClipboardData to set the data to the utf8 object.

Finally, close the clipboard with CloseClipboard.

EmptyClipboard();
SetClipboardData(CF_UNICODETEXT, object);

CloseClipboard();

Copy after login

cocoa

Start by creating an array of the type of data you want to put on the clipboard and convert it to an NSArray using initWithObjects.

NSPasteboardType ntypes[] = { dataType };

NSArray* array = ((id (*)(id, SEL, void*, NSUInteger))objc_msgSend)
                    (NSAlloc(objc_getClass("NSArray")), sel_registerName("initWithObjects:count:"), ntypes, 1);

Copy after login

Use declareTypes to declare the array as the supported data types.

You can also free the NSArray with NSRelease.

((NSInteger(*)(id, SEL, id, void*))objc_msgSend) (pasteboard, sel_registerName("declareTypes:owner:"), array, NULL);
NSRelease(array);

Copy after login

You can convert the string to want to copy to an NSString via stringWithUTF8String and set the clipboard string to be that NSString using setString.

NSString* nsstr = objc_msgSend_class_char(objc_getClass("NSString"), sel_registerName("stringWithUTF8String:"), text);

((bool (*)(id, SEL, id, NSPasteboardType))objc_msgSend) (pasteboard, sel_registerName("setString:forType:"), nsstr, dataType);

Copy after login

Full examples

X11

// compile with:
// gcc x11.c -lX11

#include
#include
#include
#include
#include

#include

int main(void) {
    Display* display = XOpenDisplay(NULL);

    Window window = XCreateSimpleWindow(display, RootWindow(display, DefaultScreen(display)), 10, 10, 200, 200, 1,
                                 BlackPixel(display, DefaultScreen(display)), WhitePixel(display, DefaultScreen(display)));

    XSelectInput(display, window, ExposureMask | KeyPressMask);

    const Atom UTF8_STRING = XInternAtom(display, "UTF8_STRING", True);
    const Atom CLIPBOARD = XInternAtom(display, "CLIPBOARD", 0);
    const Atom XSEL_DATA = XInternAtom(display, "XSEL_DATA", 0);

    const Atom SAVE_TARGETS = XInternAtom((Display*) display, "SAVE_TARGETS", False);
    const Atom TARGETS = XInternAtom((Display*) display, "TARGETS", False);
    const Atom MULTIPLE = XInternAtom((Display*) display, "MULTIPLE", False);
    const Atom ATOM_PAIR = XInternAtom((Display*) display, "ATOM_PAIR", False);
    const Atom CLIPBOARD_MANAGER = XInternAtom((Display*) display, "CLIPBOARD_MANAGER", False);

    // input
    XConvertSelection(display, CLIPBOARD, UTF8_STRING, XSEL_DATA, window, CurrentTime);
    XSync(display, 0);

    XEvent event;
    XNextEvent(display, &event);

    if (event.type == SelectionNotify && event.xselection.selection == CLIPBOARD && event.xselection.property != 0) {

        int format;
        unsigned long N, size;
        char* data, * s = NULL;
        Atom target;

        XGetWindowProperty(event.xselection.display, event.xselection.requestor,
            event.xselection.property, 0L, (~0L), 0, AnyPropertyType, &target,
            &format, &size, &N, (unsigned char**) &data);

        if (target == UTF8_STRING || target == XA_STRING) {
            printf("paste: %s\n", data);
            XFree(data);
        }

        XDeleteProperty(event.xselection.display, event.xselection.requestor, event.xselection.property);
    }

    // output
    char text[] = "new string\0";

    XSetSelectionOwner((Display*) display, CLIPBOARD, (Window) window, CurrentTime);

    XConvertSelection((Display*) display, CLIPBOARD_MANAGER, SAVE_TARGETS, None, (Window) window, CurrentTime);

    Bool running = True;
    while (running) {
        XNextEvent(display, &event);
        if (event.type == SelectionRequest) {
            const XSelectionRequestEvent* request = &event.xselectionrequest;

            XEvent reply = { SelectionNotify };
            reply.xselection.property = 0;

            if (request->target == TARGETS) {
                const Atom targets[] = { TARGETS,
                                        MULTIPLE,
                                        UTF8_STRING,
                                        XA_STRING };

                XChangeProperty(display,
                    request->requestor,
                    request->property,
                    4,
                    32,
                    PropModeReplace,
                    (unsigned char*) targets,
                    sizeof(targets) / sizeof(targets[0]));

                reply.xselection.property = request->property;
            }

            if (request->target == MULTIPLE) {
                Atom* targets = NULL;

                Atom actualType = 0;
                int actualFormat = 0;
                unsigned long count = 0, bytesAfter = 0;

                XGetWindowProperty(display, request->requestor, request->property, 0, LONG_MAX, False, ATOM_PAIR, &actualType, &actualFormat, &count, &bytesAfter, (unsigned char **) &targets);

                unsigned long i;
                for (i = 0; i < count; i += 2) {
                    Bool found = False;

                    if (targets[i] == UTF8_STRING || targets[i] == XA_STRING) {
                        XChangeProperty((Display*) display,
                            request->requestor,
                            targets[i + 1],
                            targets[i],
                            8,
                            PropModeReplace,
                            (unsigned char*) text,
                            sizeof(text));
                        XFlush(display);
                        running = False;
                    } else {
                        targets[i + 1] = None;
                    }
                }

                XChangeProperty((Display*) display,
                    request->requestor,
                    request->property,
                    ATOM_PAIR,
                    32,
                    PropModeReplace,
                    (unsigned char*) targets,
                    count);

                XFlush(display);
                XFree(targets);

                reply.xselection.property = request->property;
            }

            reply.xselection.display = request->display;
            reply.xselection.requestor = request->requestor;
            reply.xselection.selection = request->selection;
            reply.xselection.target = request->target;
            reply.xselection.time = request->time;

            XSendEvent((Display*) display, request->requestor, False, 0, &reply);
            XFlush(display);
        }
    }

    XCloseDisplay(display);
 }

Copy after login

Winapi

// compile with:
// gcc win32.c

#include <windows.h>
#include <locale.h>

#include <stdio.h>

int main() {
    // output
    if (OpenClipboard(NULL) == 0)
        return 0;

    HANDLE hData = GetClipboardData(CF_UNICODETEXT);
    if (hData == NULL) {
        CloseClipboard();
        return 0;
    }

    wchar_t* wstr = (wchar_t*) GlobalLock(hData);

    setlocale(LC_ALL, "en_US.UTF-8");

    size_t textLen = wcstombs(NULL, wstr, 0);

    if (textLen) {
        char* text = (char*) malloc((textLen * sizeof(char)) + 1);

        wcstombs(text, wstr, (textLen) + 1);
        text[textLen] = '\0';

        printf("paste: %s\n", text);
        free(text);
    }

    GlobalUnlock(hData);
    CloseClipboard();


    // input

    char text[] = "new text\0";

    HANDLE object = GlobalAlloc(GMEM_MOVEABLE, (sizeof(text) / sizeof(char))  * sizeof(WCHAR));

    WCHAR* buffer = (WCHAR*) GlobalLock(object);
    if (!buffer) {
        GlobalFree(object);
        return 0;
    }

    MultiByteToWideChar(CP_UTF8, 0, text, -1, buffer, (sizeof(text) / sizeof(char)));

    GlobalUnlock(object);
    if (OpenClipboard(NULL) == 0) {
        GlobalFree(object);
        return 0;
    }

    EmptyClipboard();
    SetClipboardData(CF_UNICODETEXT, object);
    CloseClipboard();
}

Copy after login

Cocoa

// compile with:
// gcc cocoa.c -framework Foundation -framework AppKit


#include
#include
#include
#include

#ifdef __arm64__
/* ARM just uses objc_msgSend */
#define abi_objc_msgSend_stret objc_msgSend
#define abi_objc_msgSend_fpret objc_msgSend
#else /* __i386__ */
/* x86 just uses abi_objc_msgSend_fpret and (NSColor *)objc_msgSend_id respectively */
#define abi_objc_msgSend_stret objc_msgSend_stret
#define abi_objc_msgSend_fpret objc_msgSend_fpret
#endif

typedef void NSPasteboard;
typedef void NSString;
typedef void NSArray;
typedef void NSApplication;

typedef const char* NSPasteboardType;

typedef unsigned long NSUInteger;
typedef long NSInteger;

#define NSAlloc(nsclass) objc_msgSend_id((id)nsclass, sel_registerName("alloc"))

#define objc_msgSend_bool           ((BOOL (*)(id, SEL))objc_msgSend)
#define objc_msgSend_void           ((void (*)(id, SEL))objc_msgSend)
#define objc_msgSend_void_id        ((void (*)(id, SEL, id))objc_msgSend)
#define objc_msgSend_uint           ((NSUInteger (*)(id, SEL))objc_msgSend)
#define objc_msgSend_void_bool      ((void (*)(id, SEL, BOOL))objc_msgSend)
#define objc_msgSend_void_int       ((void (*)(id, SEL, int))objc_msgSend)
#define objc_msgSend_bool_void      ((BOOL (*)(id, SEL))objc_msgSend)
#define objc_msgSend_void_SEL       ((void (*)(id, SEL, SEL))objc_msgSend)
#define objc_msgSend_id             ((id (*)(id, SEL))objc_msgSend)
#define objc_msgSend_id_id              ((id (*)(id, SEL, id))objc_msgSend)
#define objc_msgSend_id_bool            ((BOOL (*)(id, SEL, id))objc_msgSend)

#define objc_msgSend_class_char ((id (*)(Class, SEL, char*))objc_msgSend)

void NSRelease(id obj) {
    objc_msgSend_void(obj, sel_registerName("release"));
}

int main() {
    /* input */
    NSPasteboardType const NSPasteboardTypeString = "public.utf8-plain-text";

    NSString* dataType = objc_msgSend_class_char(objc_getClass("NSString"), sel_registerName("stringWithUTF8String:"), (char*)NSPasteboardTypeString);

    NSPasteboard* pasteboard = objc_msgSend_id((id)objc_getClass("NSPasteboard"), sel_registerName("generalPasteboard"));

    NSString* clip = ((id(*)(id, SEL, const char*))objc_msgSend)(pasteboard, sel_registerName("stringForType:"), dataType);

    const char* str = ((const char* (*)(id, SEL)) objc_msgSend) (clip, sel_registerName("UTF8String"));

    printf("paste: %s\n", str);

    char text[] = "new string\0";

    NSPasteboardType ntypes[] = { dataType };

    NSArray* array = ((id (*)(id, SEL, void*, NSUInteger))objc_msgSend)
                        (NSAlloc(objc_getClass("NSArray")), sel_registerName("initWithObjects:count:"), ntypes, 1);

    ((NSInteger(*)(id, SEL, id, void*))objc_msgSend) (pasteboard, sel_registerName("declareTypes:owner:"), array, NULL);
    NSRelease(array);

    NSString* nsstr = objc_msgSend_class_char(objc_getClass("NSString"), sel_registerName("stringWithUTF8String:"), text);

    ((bool (*)(id, SEL, id, NSPasteboardType))objc_msgSend) (pasteboard, sel_registerName("setString:forType:"), nsstr, dataType);
}

Copy after login

The above is the detailed content of RGFW Under the Hood: Clipboard Copy/Paste. For more information, please follow other related articles on the PHP Chinese website!
